Ubiquiti UniFi U7 Pro Max Wi-Fi 7 Access Point

General Description

Deliver high-capacity wireless connectivity across demanding business, hospitality or advanced home environments with the Ubiquiti UniFi U7 Pro Max. This ceiling or wall-mounted Wi-Fi 7 access point operates across the 2.4GHz, 5GHz and 6GHz bands, providing greater capacity for modern wireless devices.

Its eight spatial streams include a powerful 4×4 MU-MIMO 5GHz radio, while the 6GHz radio supports channel widths up to 320MHz. With capacity for more than 500 clients, coverage of up to 160m² and a 2.5GbE uplink, the U7 Pro Max is designed for busy, large-scale networks.

Key Features

• Wi-Fi 7 performance: Supports the latest IEEE 802.11be wireless standard.

• Tri-band connectivity: Operates across 2.4GHz, 5GHz and 6GHz.

• Eight spatial streams: Provides increased capacity for high-density environments.

• 4×4 MU-MIMO on 5GHz: Improves performance when serving multiple compatible devices.

• 6GHz support: Provides access to cleaner spectrum for compatible Wi-Fi 6E and Wi-Fi 7 clients.

• Up to 320MHz channels: Enables high wireless throughput on compatible 6GHz devices.

• 500+ client capacity: Designed for large offices, venues, schools and hospitality environments.

• Up to 160m² coverage: Covers a substantial indoor area when correctly positioned.

• 2.5GbE uplink: Reduces wired-backhaul bottlenecks.

• Dedicated spectral scanning: Provides real-time visibility into radio-frequency interference.

• Zero-Wait DFS: Helps maintain connectivity while using supported DFS channels.

• PoE+ power: Uses one Ethernet cable for power and network data.

• Centralised management: Configured and monitored through the UniFi Network platform.

Technical Specifications

Specification	Details
Brand	Ubiquiti
Product range	UniFi
Model	U7 Pro Max / U7-Pro-Max
Wi-Fi standard	Wi-Fi 7 / IEEE 802.11be
Frequency bands	2.4GHz, 5GHz and 6GHz
Spatial streams	8
2.4GHz MIMO	2×2 MU-MIMO
5GHz MIMO	4×4 MU-MIMO
6GHz MIMO	2×2 MU-MIMO
Maximum 2.4GHz data rate	688Mbps
Maximum 5GHz data rate	8.6Gbps
Maximum 6GHz data rate	5.8Gbps
Network interface	1 × 1/2.5GbE RJ45
Coverage area	Up to 160m²
Client capacity	500+
Maximum BSSIDs	8 per radio
Power method	PoE+
Supported voltage	44–57V DC
Maximum power consumption	25W
Dimensions	Ø206 × 46 mm
Weight	680g
Enclosure	Polycarbonate and aluminium
Mounting	Ceiling or wall
Operating temperature	-30°C to 50°C
UniFi Network requirement	Version 8.2.93 or later
Intended environment	Indoor

Network Requirements

The U7 Pro Max requires:

• A PoE+ switch or compatible PoE+ injector

• Cat5e or better Ethernet cabling; Cat6 is recommended for 2.5GbE

• A UniFi Console, Cloud Gateway or compatible UniFi Network application

• Compatible client devices for Wi-Fi 7 and 6GHz functionality

Availability and permitted use of the 6GHz band depend on local regulations and the configured country or region.

Package Contents

• 1 × Ubiquiti UniFi U7 Pro Max Access Point

• 1 × Professional ceiling/wall mounting assembly

• 1 × Installation hardware

• 1 × Installation documentation

PoE+ injector, network switch and Ethernet cable are not included unless specifically stated.

Important Information

Advertised data rates are theoretical wireless link speeds and do not represent guaranteed internet performance. Actual results depend on connected devices, interference, channel configuration, cabling, uplink speed and internet service.

The U7 Pro Max is an access point, not a standalone modem or router. Professional planning and installation are recommended for large-scale deployments.
